Ratchet Hand Puller
The JHW ratchet hand puller is a manually operated wire rope puller. Compare the listed 1–2 metric tonne models and confirm the applicable rating for your intended task.
The JHW Series Wire Rope Hoist features a compact structure, flexible operation, and a durable steel construction. It is suitable for pulling, lifting, tensioning, and positioning applications in workshops, warehouses, construction sites, and maintenance areas.
- Compact structure, flexible application, and simple manual operation.
- High-strength gears and a high-quality carbon-steel construction.
- 360-degree rotating design for convenient operation from different directions.
- Equipped with an automatic braking device for improved operational safety.
- Specially heat-treated components provide excellent durability and resistance to deformation.
- Available rated capacities from 1 ton to 2 tons.
Description
JHW Ratchet Hand Puller for Lifting, Pulling and Load Positioning
The KKV JHW Ratchet Hand Puller is a compact manually operated
device designed for controlled lifting, pulling, tensioning
and positioning operations.
Its portable ratchet-operated design makes it suitable for
temporary work areas, workshops, construction sites,
warehouses and maintenance operations where controlled
manual load movement is required.
The JHW series is available in
1T, 1.5T and 2T rated capacities
and combines carbon-steel construction, high-strength gearing,
automatic braking and a 360° rotating design.
Built for Reliable Manual Load Control
The JHW combines a compact hand-operated mechanism with
steel wire rope and high-strength gearing to provide
controlled movement in a range of industrial applications.
Lifting
Raise loads within the rated capacity during
installation, maintenance and general material
handling work.
Pulling
Pull or move loads using controlled manual force
where powered equipment is unnecessary or unavailable.
Tensioning
Apply controlled tension during installation,
adjustment and alignment operations.
Positioning
Make gradual load or equipment adjustments where
controlled manual positioning is required.
Compact Construction for Industrial Applications
The JHW is designed around a robust manual ratchet mechanism
for portable load-handling work. Key components are selected
and treated to support reliable operation under normal
industrial working conditions.
Carbon-Steel Construction
The main structure uses high-quality carbon steel
for a robust and durable product body.
High-Strength Gears
High-strength gearing transfers manual operating
force through the ratchet mechanism.
Automatic Braking Device
The integrated braking mechanism provides controlled
load handling during operation.
Heat-Treated Components
Selected components receive heat treatment according
to the product design and manufacturing process.
360° Rotating Design
The rotating configuration improves flexibility when
positioning the puller for different working angles.
Multiple Capacities
Choose from 1T, 1.5T and 2T models according to
the required rated load.
Designed for Workshop, Construction and Maintenance Work
The compact manual design allows the JHW Ratchet Hand Puller
to be used across a variety of general industrial and field
applications.
Construction Sites
Controlled lifting, pulling, alignment and positioning
during temporary construction and installation work.
Workshops
Machinery positioning, component adjustment and
general maintenance operations.
Warehouses
Manual load movement and positioning where a compact
pulling device is preferred.
Maintenance Areas
Portable pulling and lifting for equipment repair,
assembly and servicing work.
How to Select the Right JHW Ratchet Hand Puller
Select the appropriate model according to rated load,
wire rope specification, working space and actual operating
requirements.
01
Required Rated Load
Select a model whose rated capacity covers the
maximum intended working load. Available models
are rated at 1T, 1.5T and 2T.
02
Wire Rope Diameter
JHW models use either 5 mm or 6 mm diameter
steel wire rope according to capacity.
03
Working Distance
The standard wire rope length is 2800 mm.
Confirm that this operating range suits the
intended lifting or pulling task.
04
Available Working Space
Allow sufficient room for the puller body,
operating handle, attachment points and wire
rope movement.
05
Application Type
Consider whether the unit will mainly be used
for lifting, pulling, tensioning or positioning
when selecting the appropriate capacity.
Inspection Before Shipment
Each JHW Ratchet Hand Puller is inspected before shipment
as part of KKV quality-control procedures.
Ratchet Mechanism
Manual operating and ratchet functions are checked
for correct movement.
Braking Function
The automatic braking mechanism is checked for
normal operation.
Wire Rope
Wire rope condition and installation are checked
before packing.
External Components
Body, handle, attachment parts and visible components
are inspected before shipment.
CE-Certified JHW Ratchet Hand Puller
The KKV JHW Ratchet Hand Puller series is CE-certified
for the applicable product configurations.
Three Capacities for Different Load Requirements
1.0T rated load
1.5T rated load
2.0T rated load
2800 mm
Routine Checks for Reliable Operation
deformation, corrosion or excessive wear before use.
abnormal movement or visible damage.
before applying the working load.
before each operation.
and never use the product to lift personnel.
JHW Ratchet Hand Puller Ordering Questions
Does the listed 2.8 m rope length mean 2.8 m of usable travel?
The specification table lists rope length. Confirm the usable operating distance for the selected JHW model and attachment arrangement before ordering.
What information is needed for a quotation?
Provide the JHW model, intended task, load or pulling requirement, attachment arrangement, required working distance, quantity and destination. Ask KKV to confirm the applicable rating and instructions for the proposed setup.
Need Technical Information?
Compare rated loads, wire rope sizes,
overall dimensions and product weights.
Coming Soon
Additional information
| Rated Capacity | 1-2T |
|---|---|
| Test Load | 1.5 × Rated Capacity |
| Net Weight | 3.3~4.7KG |
JHW Ratchet Hand Puller Specifications
Compare rated load, wire rope size, overall dimensions and net weight across the JHW product range.
| Model | JHW-1000 | JHW-1500 | JHW-2000 |
|---|---|---|---|
| Rated Load (t) | 1.0 | 1.5 | 2.0 |
| Wire Rope Diameter × Length (mm) | 5 × 2800 | 6 × 2800 | 6 × 2800 |
| Overall Size (mm) | 580 | 680 | 680 |
| Net Weight (kg) | 3.30 | 4.35 | 4.70 |
