HGS-B Mini Electric Wire Rope Hoist
The HGS-B Mini Electric Wire Rope Hoist is a compact
electric lifting solution designed for workshops, warehouses,
garages, construction sites and light-duty material-handling applications.
The series supports both single-hook and double-hook lifting configurations.
- Single-hook and double-hook lifting configurations.
- Rated capacities from 100/200 kg to 500/1000 kg.
- 220/230 V, 50 Hz power supply.
- Emergency stop switch for quick shutdown.
- Reinforced braking limit switch with position protection.
- Protection rating up to IP54.
- Built-in thermal overload protection.
- Standard motor and copper-winding motor options available.
When comparing a small electric cable hoist, use the capacity for the intended hook arrangement. Specify the load in kilograms, required lift and site voltage and frequency when requesting a quotation.
Description
HGS-B Mini Electric Wire Rope Hoist
for Compact Material Handling
The HGS-B Mini Electric Wire Rope Hoist
is a compact electrically powered lifting solution designed
for workshops, warehouses, garages, construction sites and
other light-duty material-handling applications.
The HGS-B series combines a compact lifting unit with
single-hook and double-hook configurations,
allowing users to select between lifting height, lifting
speed and available load capacity according to the job.
The current product range includes
PA-200 to PA-1000 models, with listed
lifting capacities ranging from
100/200 kg to 500/1000 kg.
Compact Electric Lifting with Integrated Protection
The HGS-B is designed for applications where a full-size
industrial wire rope hoist is unnecessary but powered lifting
can improve material-handling efficiency.
Compact Structure
The compact body makes the HGS-B suitable for
workshops, garages, storage areas and other
locations where installation space is limited.
Emergency Stop
An emergency stop switch allows the operator to
quickly interrupt powered operation when required.
Position Limit Protection
A reinforced braking limit switch provides
position protection during lifting operation.
Thermal Protection
Built-in thermal overload protection helps protect
the electric drive system against excessive
operating temperature.
IP54 Protection
The listed HGS-B configuration provides a
protection rating of up to IP54.
Multiple Model Options
PA-200 through PA-1000 models provide multiple
lifting-capacity and motor-power options for
different light material-handling requirements.
Single-Hook and Double-Hook Lifting
One of the main advantages of the HGS-B series is the ability
to operate in either a single-hook or double-hook lifting
configuration.
Changing the lifting arrangement changes the available
capacity, lifting height and lifting speed, allowing users
to prioritize either greater lifting travel or increased
lifting capacity.
Single-Hook Configuration
The listed single-hook configuration provides
the higher lifting speed and greater lifting
height within the HGS-B specification series.
Double-Hook Configuration
The double-hook arrangement increases the listed
lifting capacity while reducing lifting speed
and available lifting height.
10 / 5 m/min Lifting Speed and 12 / 6 m Lift
The listed HGS-B specification uses paired operating values
according to the single-hook or double-hook configuration.
Single-Hook Lifting
Listed lifting speed: 10 m/min.
Double-Hook Lifting
Listed lifting speed: 5 m/min.
Single-Hook Lift
Listed lifting height: 12 m.
Double-Hook Lift
Listed lifting height: 6 m.
Multiple Protection Features for Powered Lifting
The HGS-B incorporates several protection features designed
around routine electric lifting operation.
Emergency Stop Switch
Provides a direct way to stop powered operation
when an immediate shutdown is required.
Braking Limit Switch
Reinforced position-limit protection helps control
the permitted lifting travel.
Thermal Overload Protection
Helps protect the motor system against excessive
temperature during operation.
Up to IP54
The listed protection rating is suitable for the
intended general material-handling configuration.
Standard and Copper-Winding Motor Options
The HGS-B series is available with
standard motor or copper-winding motor options
according to product configuration and ordering requirements.
Listed input power increases across the PA model range,
from 510 W on PA-200 to
2000 W on PA-1000.
Confirm the required model, lifting configuration and motor
option when requesting a quotation.
220 / 230 V Electric Hoist
The listed HGS-B specification uses a
220 / 230 V, 50 Hz power supply.
This electrical configuration helps position the HGS-B as
a compact powered lifting solution for smaller industrial,
workshop and material-handling applications rather than
a large three-phase crane hoist system.
Where Is the HGS-B Mini Electric Hoist Used?
Workshops
Powered lifting of components, tools and smaller
equipment during assembly and maintenance work.
Warehouses
Light-duty lifting and material positioning in
storage and handling areas.
Garages
Compact electric lifting for maintenance,
repair and equipment-handling tasks.
Construction Sites
Lifting smaller materials and equipment where
a compact electrically powered hoist is appropriate.
How to Select the Right HGS-B Mini Electric Wire Rope Hoist
01
Determine Required Capacity
Current listed models provide paired rated
capacities from 100/200 kg up to 500/1000 kg.
Select a configuration that covers the maximum
intended working load.
02
Single or Double Hook?
Use the single-hook configuration when greater
lifting height and faster lifting speed are
preferred, or the double-hook arrangement when
increased rated lifting capacity is required.
03
Check Lifting Height
The listed configuration provides 12 m and 6 m
lifting-height options according to the selected
hook arrangement.
04
Confirm Power Supply
The listed HGS-B specification uses
220 / 230 V, 50 Hz power.
05
Select Motor Option
Confirm whether the required order uses the
standard motor or copper-winding motor option.
HGS-B Mini Electric Wire Rope Hoist Models
100 / 200 kg
125 / 250 kg
150 / 300 kg
200 / 400 kg
250 / 500 kg
300 / 600 kg
400 / 800 kg
500 / 1000 kg
Routine Checks Before Electric Lifting
excessive wear or other visible damage before operation.
the intended working load.
before normal operation.
connections for damage before use.
working conditions and investigate abnormal temperature,
sound or movement.
configuration and never use the hoist for lifting personnel.
HGS-B Mini Electric Wire Rope Hoist FAQs
How do single-hook and double-hook ratings differ?
The double-hook arrangement increases the listed capacity but reduces travel from 12 m to 6 m and speed from 10 to 5 m/min. Check the selected model’s paired kg rating.
What supply does the published HGS-B use?
The table specifies 220/230 V at 50 Hz. Provide local electrical requirements before ordering; other supplies are not confirmed here.
What should I specify for a quotation?
Send load mass, hook arrangement, required travel, motor preference, quantity and destination.
Need Help Choosing an HGS-B Model?
Compare single-hook and double-hook capacity,
lifting speed, lifting height, input power,
product weight and packing dimensions.
Coming Soon
Additional information
| Rated Capacity | 100–1000 kg |
|---|---|
| Hook Type | Single / Double |
| Lifting Height | 12 / 6 m |
HGS-B Mini Electric Wire Rope Hoist Specifications
Compare hook configuration, input power, rated lifting capacity, lifting speed, lifting height, packing dimensions and product weight across the HGS-B range.
| Model | PA-200 | PA-250 | PA-300 | PA-400 | PA-500 | PA-600 | PA-800 | PA-1000 |
|---|---|---|---|---|---|---|---|---|
| Hook Configuration | Single / Double | Single / Double | Single / Double | Single / Double | Single / Double | Single / Double | Single / Double | Single / Double |
| Rated Voltage | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz | 220 / 230 V, 50 Hz |
| Input Power (W) | 510 | 530 | 600 | 880 | 930 | 1150 | 1800 | 2000 |
| Rated Capacity (kg) | 100 / 200 | 125 / 250 | 150 / 300 | 200 / 400 | 250 / 500 | 300 / 600 | 400 / 800 | 500 / 1000 |
| Lifting Speed (m/min) | 10 / 5 | 10 / 5 | 10 / 5 | 10 / 5 | 10 / 5 | 10 / 5 | 10 / 5 | 10 / 5 |
| Lifting Height (m) | 12 / 6 | 12 / 6 | 12 / 6 | 12 / 6 | 12 / 6 | 12 / 6 | 12 / 6 | 12 / 6 |
| Quantity per Carton | 2 | 2 | 2 | 2 | 2 | 2 | 2 | 1 |
| Packing Dimensions L × W × H (cm) | 36.3 × 30 × 24 | 36.3 × 30 × 24 | 36.3 × 30 × 24 | 41.5 × 32.6 × 26.8 | 41.5 × 32.6 × 26.8 | 41.5 × 32.6 × 26.8 | 55.5 × 24.5 × 35.5 | 55.5 × 24.5 × 35.5 |
| Gross / Net Weight (kg) | 23.4 / 22.4 | 23.4 / 22.4 | 23.4 / 22.4 | 35.8 / 34.8 | 35.8 / 34.8 | 37.4 / 36.4 | 38 / 37 | 38.8 / 37 |
