DHS Electric Chain Hoist
The DHS Electric Chain Hoist is a compact
electrically powered lifting solution designed for factories,
warehouses, workshops and general industrial material handling.
It can be used for fixed-point lifting or combined with a
compatible trolley and beam system for horizontal load movement.
- Rated capacities from 1T to 5T.
- Compact structure for convenient installation.
- Suitable for fixed suspension and trolley-mounted operation.
- Compatible with I-beams, curved tracks and cantilever crane systems.
- 380V electric motor configuration.
- Available with 3 m and 6 m lifting-height configurations.
- Suitable for factories, warehouses, workshops and equipment lifting.
For a compact 380 V electric chain hoist quotation, send the load in kilograms or metric tonnes, 3 m or 6 m lift requirements, and fixed or trolley-mounted installation details. Confirm phase and frequency before ordering.
Description
DHS Electric Chain Hoist for Compact Industrial Lifting
The DHS Electric Chain Hoist is a compact
electrically powered lifting solution designed for vertical
lifting and material-handling applications in factories,
warehouses, workshops and other industrial environments.
The DHS can be installed at a
fixed suspension point or combined with a
compatible trolley and beam system where horizontal load
movement is required.
The current listed DHS range covers rated capacities from
1T to 5T and uses a
380V electric motor configuration.
Compact Electric Lifting for Everyday Material Handling
Compact Structure
The compact DHS configuration helps simplify installation
where a relatively small electric chain hoist is required
for routine lifting operations.
1T–5T Capacity Range
Current listed models include 1T, 2T, 3T and 5T
capacities for different industrial lifting requirements.
Fixed Suspension
The DHS can be installed at a fixed lifting point
when only vertical movement is required.
Trolley-Mounted Operation
A compatible trolley arrangement allows the suspended
load to travel horizontally along an appropriate beam.
380V Electric Drive
All currently listed DHS models use a 380V
electric motor configuration.
3 m / 6 m Lift Options
Product weight data is provided for both 3 m and
6 m lifting configurations across the listed series.
Flexible Installation for Different Lifting Systems
The DHS Electric Chain Hoist can be integrated into different
lifting arrangements depending on whether the application
requires fixed vertical lifting or horizontal load movement.
Fixed Suspension Point
Suitable for lifting from one defined position where
horizontal travel is not required.
I-Beam Installation
Can be combined with a compatible trolley for beam
travel applications.
Curved Track
The product can be used with compatible curved-track
lifting arrangements.
Cantilever Crane
Suitable for compatible cantilever crane systems
used for lifting and positioning loads.
Motor Power Matched to Rated Capacity
The DHS series uses different motor power configurations
according to rated lifting capacity.
DHS1
1T rated capacity with YE500W motor.
DHS2
2T rated capacity with YE500W motor.
DHS3
3T rated capacity with YE500W motor.
DHS5
5T rated capacity with YE750W motor.
Capacity-Specific Lifting Speed
Lifting speed varies across the DHS range according to
rated capacity.
2.5 m/min
2.0 m/min
1.25 m/min
1.0 m/min
Typical DHS Electric Chain Hoist Applications
Factories
Electric lifting of components, workpieces and equipment
during production and assembly operations.
Warehouses
Material lifting and positioning for routine storage
and handling operations.
Workshops
Useful for maintenance, equipment installation,
machine-tool handling and general workshop lifting.
Industrial Workstations
Fixed or trolley-mounted lifting where powered
material handling is required.
How to Select the Right DHS Electric Chain Hoist
01
Rated Capacity
Choose from the listed 1T, 2T, 3T or 5T models
according to the maximum intended working load.
02
Lifting Height
Confirm whether the application requires the
3 m or 6 m lifting configuration.
03
Fixed or Travelling?
Select fixed suspension for vertical lifting only,
or a compatible trolley arrangement when horizontal
beam travel is required.
04
Lifting Speed
Compare the listed lifting speed for each capacity
before selecting the required model.
05
Power Supply
The current listed DHS specification uses
380V electrical power.
DHS Electric Chain Hoist Models
1T / 2.5 m/min
2T / 2.0 m/min
3T / 1.25 m/min
5T / 1.0 m/min
Routine Checks Before Electric Lifting
for excessive wear, deformation or damage before use.
applying the intended working load.
normal material-handling work.
and beam condition before operation.
for damage before use.
and never use the hoist for lifting personnel.
DHS Electric Chain Hoist FAQs
Which lifting heights are listed?
The page provides 3 m and 6 m configurations. Confirm the required lift and capacity when requesting a quotation.
Is a travelling trolley included?
Do not assume inclusion. If beam travel is needed, agree a compatible trolley and installation arrangement with KKV.
What electrical information is needed?
The listed motor voltage is 380 V. Supply the site’s voltage, phase and frequency for confirmation before ordering.
Need Help Choosing a DHS Model?
Compare rated capacity, test load, motor power,
lifting speed, lifting height, product weight
and installation requirements.
Coming Soon
Additional information
| Rated Capacity | 1~5T |
|---|---|
| Test Load | 1.25~5.5T |
| Net Weight | 36~70KG |
DHS Electric Chain Hoist Specifications
Compare rated capacity, test load, motor configuration, voltage, lifting speed, product weight and packing dimensions across the DHS series.
| Model | DHS1 | DHS2 | DHS3 | DHS5 |
|---|---|---|---|---|
| Rated Capacity (t) | 1 | 2 | 3 | 5 |
| Test Load (t) | 1.25 | 2.5 | 3.5 | 5.5 |
| Motor Model / Power | YE500W | YE500W | YE500W | YE750W |
| Rated Voltage (V) | 380 | 380 | 380 | 380 |
| Lifting Speed (m/min) | 2.5 | 2 | 1.25 | 1 |
| Weight (kg) | 1 | 1 | 2 | 2 |
| Net Weight |
3 m: 36 kg 6 m: 40 kg |
3 m: 45 kg 6 m: 52 kg |
3 m: 42 kg 6 m: 50 kg |
3 m: 57 kg 6 m: 70 kg |
| Packing Dimensions L × W × H (cm) | 50 × 32 × 28 | 50 × 32 × 30 | 50 × 32 × 30 | 60 × 32 × 32 |
